Smart Scanning — Built for Professionals

GP8100

  • Available to rent
  • Available to buy
Proceq GP8100 concrete GPR array, a wide white sensor with six wheels
iPad screenshot of a GP8100 superline scan showing six side-by-side radar channels

Portable concrete GPR array for quick object detection and dense data collection in one pass.

The GP8100 is a portable concrete GPR array for crews who need to cover width quickly and still collect dense data. Smart Scanning describes it as a highly productive unit for object detection and superior data collection.

A superline scan shows objects across the array in one view, so a single pass can replace several overlapping lines. Area scans use a flexible grid. The display is a compatible Apple iPad.

Smart Scanning rents and sells the GP8100. Ask Winnipeg for availability before you book a deck, slab, or parking-garage program.

  • Large scan width, high scan rate, and strong penetration for an array of this size
  • Superline scan view for objects of different sizes
  • Dense GPR data from one superline pass
RentBuy

Specifications

Figures below are taken from Smart Scanning's product pages or from Screening Eagle's public product sheets. Where a number is not published, it is left off.

Measurement modes

  • Superline scan (1,000 m / 3,281 ft)
  • Area scan with flexible grid up to 100 m² / 1,076 ft²

Review modes

  • Superline scan
  • A-scan, including envelope
  • Migrated and non-migrated views
  • Split view
  • Time-slice view, basic
  • 3D view
  • Augmented reality

Advanced visualization

  • Time-slice view Pro
  • 3D view
  • Augmented reality

Technical specifications

  • Radar technology: stepped-frequency continuous-wave (SFCW) GPR
  • Modulated frequency range: 400–4000 MHz
  • Penetration depth: 80 cm / 31.5 in
  • Battery: flight-safe, removable pack, 8× AA (NiMH)
  • Dimensions: 41.5 × 22.5 × 13.2 cm / 16.3 × 8.9 × 5.2 in
  • Weight: 3.0 kg / 6.6 lb, excluding the battery pack

Related equipment

  • GP8000 — Portable concrete GPR for inspections and structural imaging with stepped-frequency continuous-wave radar.
  • GP8000 Lite — A simpler concrete scanner for fast detection of rebar, live wires, and other objects.
  • GP8800 — Handheld wireless concrete GPR for inspections in tight spots, using SFCW radar that fits in the palm of your hand.
